Home > Solid State Relays (S.S.R) > Solid State Relay KT Series

Solid State Relay KT1008D Series (VR - AC)(280VAC)
AC SOLID STATE RELAY
KT1008D
KT SERIES

SPECIFICATIONS
MODEL
NO.
CONTROL VOLTAGE
RANGE
MUST TURN
OFF VOLTAGE
INPUT
IMPEDANCE
MAX LOAD
CURRENT
LOAD VOLTAGE
RANGE
MIN BLOCKING
VOLTAGE
MAX OFF-STATE
LEAKAGE
FREQUENCY
RANGE
MAX 1-CYCLE
PEAK SURGE
CATALOG DOWNLOAD
KT1008D
3 TO 32 VDC
MAX10VAC
1.5Kohm
8A
120VDC
400VDC
LESS 1 mA
47~70Hz
80A

MODEL
NO.
MAX OFF
STATE dv/dt
MAX ON-STATE
VOLTAGE DROP
ISOLATE
IMPEDENCE
DIELECTRIC STRENGTH
INPUT-OUTPUT
DIELECTRIC STRENGTH
INPUT,OUTPUT-CASE
TURN ON
TIME
TURN OFF
TIME
CAPACITANCE
IN-OUT
WEIGHT (g)
KT1008D
200 SEC
1.2Vrms
ohm
2500Vrms
-
LESS2mSee
LESS 1/2 AC CYCLE
LESS 15 PF
10 g

OUTLINE DIMENSIONS
EQUIVALENT CIRCUIT
